NSAL-72 - Slot diffuser
The NSAL-72 slot diffuser is designed to supply air in rooms requiring high comfort (e.g. offices, public buildings and laboratories). Adapted for installation in ceilings. Recommended installation height from 2.5 to 4 m. The diffuser can be used as an exhaust element.
A slot diffuser with adjustable vanes designed for fixed or variable outputs. The adjustment of air flow direction using a sliding vane allows to set the horizontal or vertical direction. The special design allows the maximum use of the Coanda effect. Standard lengths of the NSAL-72 diffusers are 600, 1,000, 1,200,
1,500, 1,800 and 2,000 mm. On request, it is possible to make a diffuser of any length in the range of 300–2,000 mm. The width of a single slot, depending on the version, is 18 or 25 mm. The plenum box is made of galvanized steel sheet with or without insulation. It is possible to install a control damper (deflector) in the
spigots. The front panel and vanes are made of anodized aluminium profiles or painted in a RAL9010 colour. On request, it is possible to paint the parts in another RAL colour. Black vanes as standard.
